Cold rolled HSS strip: Width 25-55mm thickness 0.60-1.80 mm
Hot rolled HSS strip: Width 36-65mm thickness 1.5-3.0mm
High-speed steel contains 0.6~1.3 % C and less S & P. It becomes alloy steel through adding W, Cr, Mo, Co, V and Mn. Among those elements, W, Mo and Co can improve strength of steel. The Cr enhance the oxidation resistance and wear resistance of steel. V improve the impact resistance, and Mn can improve the toughness of steel.
Shanghai Metal Corporation HSS is produced with electro-slag re-melting (ESR) or ladle furnace (LF) + vacuum degassing (VD) refine technology. With 30 years development, SMC has been forming a complete range of steel grade, the quality of HSS has reached an international level. Because of totally control chemical composition, size precision, alloy content, carbon saturation and purity, it makes it possible to offer a guarantee to customers in the reliability and identity of heat treatment performance and utilization property.
Shanghai metal Corporation is a professional manufacturer and supplier of high speed steel with high quality and reasonable price. If you want to know more about high speed steel products or high speed steel price please feel free to contact us, we will reply you within 24 hours.
Cold rolled strip: width 25-55mm, thickness 0.65-1.80 mm
Hot rolled strip: width 36-65mm, thickness 1.5-3.0mm
Steel Grade: M2, M35, M40 , M42 etc (usually )
Delivery status: annealed, quenched, tempered
Surface: black, grinding, polishing, bright
1. Gear Cutter
2. Hacksaw blade
3. Saw blades
4. Slitting saw
5. Circular saw blade
6. Cutting blade
7. Power planner replaceble blade
8. Sugar cane juice extractor blade
Technical Information of High Speed Steel Strip/Tape:
Steel Type |
Steel Grade |
||||||
GB9943 |
ISO 4957 |
JIS |
AISI |
ERASTEEL |
BOHLER |
||
HSS-E |
>4 5%Co |
W2MO9C「4VCO8 |
HS2-9-1-8 |
SKH59 |
M42 |
EM42 |
S500 |
W6Mo5Cr4V2Co5 |
HS6-5-2-5 |
SKH55 |
(M35) |
EM35 |
S705 |
||
VV7Mo4Cr4V2Co5 |
|
|
M41 |
|
|
||
W12Cr4V5Co5 |
HS12-1-5-5 |
SKH10 |
T15 |
|
|
||
W10Mo4Cr4V3Co10 |
HS10-4-3-10 |
SKH57 |
(T42) |
WKE42 |
S700 |
||
1%AI |
W6M05Cr4V2AI |
|
|
|
|
S620 |
|
>2.5%V |
W6Mo5Cr4V3 |
HS6-5-3 |
SKH53 |
M3-2 |
EM3 2 |
S607 |
|
CVV6Mo5Cr4V3 |
HS6-5-3C |
|
|
|
|
||
W6M05Cr4V4 |
HS6-5-4 |
SKH54 |
M4 |
|
|
||
HSS |
W6Mo5Cr4V2 |
HS6-5-2 |
SKH51 |
M2 |
|
|
|
VV6M05Cr4V2 |
HS6-5-2 |
SKH51 |
M2 |
|
|
||
CW6Mo5Cr4V2 |
HS6-5-2C |
|
CM2 |
EM2 |
S600 |
||
W6M06Cr4V2 |
HS6-6-2 |
|
|
|
|
||
(VV6Mo3Cr4V2) |
|
|
|
|
|
||
W9Mo3Cr4V |
|
|
|
|
|
||
VV2Mo8Cr4V |
HS1-8-1 |
|
M1 |
|
|
||
W2Mo9Cr4V2 |
HS2-9-2 |
SKH58 |
M7 |
EM7 |
S400 |
||
W18Cr4V |
HS18-0-1 |
SKH2 |
T1 |
ET1 |
S200 |
||
HSS-L |
W1 Mo4Cr4V2 |
HS1-4-2 |
|
M52 |
|
|
|
W4Mo3Cr4VSi |
|
|
|
|
|
||
W3M03C「4V2 |
HS3-3-2 |
|
|
ABCIII |
|
||
(W3Mo2Cr4V2Si) |
|
|
|
|
|
Chemical Component:
Grade |
Chemical Component |
||||||||
C |
Si |
Mn |
P |
S |
Cr |
Mo |
W |
V |
|
1.3343 |
0.86-0.94 |
≤0.45 |
≤0.40 |
≤0.030 |
≤0.030 |
3.80-4.50 |
4.70-5.20 |
5.90-6.70 |
1.70-2.10 |
M2 |
0.78-0.88 |
0.20-0.45 |
0.15-0.40 |
≤0.030 |
≤0.030 |
3.75-4.50 |
4.50-5.50 |
5.50-6.75 |
1.75-2.20 |
W6Mo5Cr4V2 |
0.80-0.90 |
0.20-0.45 |
0.15-0.40 |
≤0.030 |
≤0.030 |
3.80-4.40 |
4.50-5.50 |
5.50-6.75 |
1.75-2.20 |
Physical Property:
Temperature °C |
Density g/cm3 |
Modulus of elasticity |
Coefficient of thermal expansion |
Heat transfer coefficient |
Specific heat |
KN/mm2 |
W/m°C |
J/kg°C |
|||
20 |
8.16 |
225 |
/ |
24 |
420 |
400 |
8.06 |
200 |
1.21×10-6 |
28 |
510 |
600 |
8 |
180 |
1.26×10-6 |
27 |
600 |
Packaging of High Speed Steel Strip/Tape/Sheet:
Shanghai Metal Corporation Products are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.
1)SMC Standard
2)Customization
