Material: carbon steel

Grade: Q345B, API X42-X80, L245, J55

Standard: SY/T5037-2000,GB/T9711 etc.

Product Detail | Technical Information | Packaging | More

Product Detail

ERW Pipe is Electric Resistance Welded Pipe; it is widely used in fencing, scaffolding, engineering, etc. Our company can produce wide range of sizes which could satisfy the requirements from customers. Shanghai Metal Corporation has always held the management concept of “quality first, credit first, customer first” to develop constantly, we have always persisted in scientific innovation. If you want to know more about the products, please feel free to contact us, we will reply you within 24 hours.

Standard: ASTM A53/A53M, ASTM A252, EN10219-1, AS/NZS 1163, AS/NZS 1074, ASTM A500, etc.

Size:

Outer Diameter: 21.3mm-610mm (1/2"-24")

Wall Thickness: 1mm-22mm

Length: 0.5mtr-20mtr

End: square ends (straight cut, saw cut, and torch cut). or beveled for welding, beveled,

Surface: Lightly oiled, Hot dip galvanized, Electro galvanized, Black, Bare, Varnish coating/Anti rust oil, Protective Coatings (Coal Tar Epoxy,Fusion Bond Epoxy, 3-layers PE)

Test: Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (Flattening Test, Bending Test, Blow Test, Impact Test), Exterior Size Inspection, Hydrostatic Test, X-ray Test.

Fencing

Scaffolding

Engineering

Component parts

Fluid transmission

Construction, etc.

No.	Name	Standard	Grades	Uses
1	Welded & Galvanized Steel Pipe	ASTM A53/A53M	A, B	Black and Hot-Dipped Zinc-Coated Welded Steel Pipe
2	Pipe Piles	ASTM A252	Grade1, Grade2, Grade3	Supporting Pipe Piles
3	Cold Formed Welded Structural Sections Of Non-alloy	EN10219-1 AS/NZS 1163 AS/NZS 1074	S235JRH, S275J0H, S355J0H, S355J2H, C250, C350, C450, Grade 1, Grade 2	Welded steel tubes for structures
4	Weld Carbon Steel Structural Tubing in Round, Square, and Rectangular Shapes	ASTM A500	Grade A, Grade B, Grade C, Grade D	General Structural Welded Steel Pipe

Packaging of ERW Pipe(Electric Resistance Welded Pipe):

Shangahi Metal Corporation Products are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.

1)SMC Standard

2)Customization

Service

To meet the entirety of our customers business needs, SMC offers its services as a “One-Stop Shop” for business services including Purchasing, Value-Added Manufacturing, Packaging/Labeling, and Delivery. SMC prides itself on achieving superior results and satisfying customer needs. In this, we earnestly strive to fulfill our role as trustworthy and reliable supplier of business services throughout the entire world.

Our Value-Added Manufacturing Services not only save our customer time from having to out-source, but also spare them the cost of dealing with several disparate shops and deadlines.

Applications of ERW Pipe:

Fencing

Scaffolding

Engineering

Component parts

Fluid transmission

Construction, etc.
