Coating Weight: AZ30 ~ AZ185

Spangle: Regular Spangle.

Thickness: 0.1mm – 3.0mm

Product Detail | Technical Information | Packaging | More

Product Detail

Galvalume Steel Strip is covered with aluminum-zinc alloy, which is composed of 55% aluminum, 43.4% zinc and 1.6% silicon solidified at 600 °C, the alloy coating makes the Galvalume Steel Strip has better performance, the corrosion resistance of Galvalume Steel is 2-6 times better than hot dip galvanized steel.

Shanghai Metal Corporation is experienced manufacturer Galvalume Steel Strip. If you want to know more about the product, please feel free to contact us, we will reply you within 24 hours.

1) Standard: JIS3321/ASTM A792M

2) Coating Weight: AZ30 ~ AZ185

3) Spangle: Regular Spangle.

4) Thickness: 0.1mm – 3.0mm

5) Width: 10mm - 600mm

6) Weight of each roll: according to the customer's request

7) Inner Diameter: 200/300/400/508mm

1) Composed of 55% aluminum, 43.5% zinc and 1.5% silicon

2) Formable, weldable and paintable

3) Corrosion resistance in the most atmospheric conditions. This is achieved through the combination of the sacrificial protection of the zinc and the barrier protection of the aluminum.

4) Coating out-performs galvanized coating from 2-6 times than hot dip galvanized steel

Structural sections
Composite panels
Air duct
Computer casing
Metal parts
Atomobile

Steel Type & Grade:

Steel Type	AS1397-2001	EN10215-1995	ASTM A792M-02	JIS G3312:1998	ISO9364-2001
Steel for cold forming and Deep drawing application	G2+AZ	DX51D+AZ	CS type B,type C	SGLCC	1
Steel for cold forming and Deep drawing application	G32+AZ	DX52D+AZ	DS	SGLCD	2
Structural steel	G250+AZ	S250GD+AZ	255	-	250
	G300+AZ	-	-	-	-
	G350+AZ	S350GD+AZ	345Class 1	SGLC490	350
	G550+AZ	S550GD+AZ	550	SGLC570	550

Surface Treatment:

Surface treatment	Feature
Chromated	Minimize the chance of humid-storage staining forms a dark gray surface discoloration on the surface
Chromated	Retain the bright metallic luster for a long period
Oil	Minimize the tendency for humid-storage stain
Chemical treatment and oil	The chemical treatment provides very good protection against humid-storage staining,while the oil provides lubricity for operations
Dry	Must be transported and stored with special precautions to preserve low-humidity conditions
Anti-finger print	Minimize the chance of humid-storage staining forms a dark gray surface discoloration on the surface

Packaging of Galvalume Steel Sheet:

Shanghai Metal Products are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.

1) Shanghai Metal Standard

2) Customization

Applications of Galvalume Steel Sheet:

1) Construction: roofing, cladding, structural sections, composite panels, etc.

2) Electric appliance: washing machine, refrigerators, toaster, microwave, etc.

3) Others: air duct, lighting, computer casing, etc.

Features of Galvalume Steel Coil:

1) Composed of 55% aluminum, 43.5% zinc and 1.5% silicon

2) Formable, weldable and paintable

3) Corrosion resistance in the most atmospheric conditions. This is achieved through the combination of the sacrificial protection of the zinc and the barrier protection of the aluminum.

4) Coating out-performs galvanized coating from 2-6 times than hot dip galvanized steel
