PEEK Filament

Material: 100% PEEK

Size: Dia 0.15-3.0mm

Color: Customized

Product Detail | Technical Information | Packaging

Product Detail

Shanghai Metal Corporation is a leading PEEK Filament manufacturer and supplier.

PEEK filament of high flexibility and high strength is produced through continuous extrusion moulding. It is of good dimensional stability and can be molding without break for thousands of meters, which is widely applied in 3D print industry.

If you want to know more about our PEEK products or PEEK filament price please feel free to contact us, we will reply you within 24 hours.

Steam resistant

Durable

Creep resistance

Good toughness

Good biocompatibility

1. 3D industry

2. Dry rice canvas for paper machinery

3. Heat-resistant filter cloth

4. Racquet wire

5. Fuel filter

6. Artificial ligament

7. High-temperature insulating jackets on aircraft

PEEK filament Specification Table:

Serial number	Size /mm	Serial number	Size /mm
1	0.15	6	1
2	0.2	7	1.5
3	0.25	8	1.75
4	0.3	9	2
5	0.5	10	3

*Other sizes are available for customized production.

Technique information of PEEK filament :

5600G Natural 0.2mm filament
No.	Size(mm)	Tensile Strength (MPa)	Breaking Strength (cN/tex)
1	0.221	631	56
2	0.218	711	56
3	0.212	709	58
4	0.217	709	58
5	0.22	704	57
5600GH Black 0.2mm filament
No.	Size(mm)	Tensile Strength (MPa)	Breaking Strength (cN/tex)
1	0.215	702	59
2	0.221	677	60
3	0.219	722	58
4	0.223	651	48
5	0.217	723	56

Packaging of PEEK filament:

Shanghai Metal Products are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.

1) Shanghai Metal Standard

2) Customization
