Semi-Exposed Framing Glass Curtain Wall
Material: Glass
Glass color: bronze, blue green, colorful pictures, etc
Quality control: AS2047, CE, SONCAP, etc
Standard: BS476, EN1634, etc
Shanghai Metal Corporation is a leading Semi-exposed Framing Glass Curtain Wall manufacturer and supplier.
The semi-hidden frame glass curtain wall is divided into two types: horizontally hidden and not hidden or vertically hidden. Regardless of the semi-concealed curtain wall, one of the corresponding sides is bonded to the glass assembly by structural glue, and the other corresponding side is assembled by the aluminum alloy inlaid groove glass. In other words, the glass is subjected to various loads, one corresponding edge is transferred to the aluminum alloy frame by the structural glue, and the other corresponding side is transmitted to the aluminum alloy frame by the aluminum alloy profile inlay groove. Therefore, the above-mentioned connection method of the semi-hidden frame glass curtain wall is indispensable, otherwise it will form a corresponding edge to bear the full load of the glass, which would be very dangerous.
If you want to know more about our Curtain Wall System products or Semi-exposed Framing Glass Curtain Wall price please feel free to contact us, we will reply you within 24 hours.
-
Aluminum:
Construction: Thermal Break or Non-Thermal Break
Aluminum Alloy: 6063 T5
Thickness: 1.0, 2.0mm for window& door& glass room 2.0, 2.5, 3.0mm for curtain wall
Surface Treatment: Powder-coated/Anodized/Electrophoresis/PVDF, etc.
Color: Silver/Bronze/Champagne/White/Black, etc.
Type: Low-E/Reflective/Tempered/Heat-strengthened/Floated
-
Glass:
Glazed: Single/Double/Triple
Thickness: Single: 3mm~12mm
Double: 5mm+6A+5mm/5mm+9A+5mm/6mm+9A+6mm, etc.
Triple: 5mm+6A+5mm+6A+5mm or others.
Color: Clear/Grey/Blue/Light Green, etc.
-
Hardware:
1 Chinese Famous Brand or German Brand.
2 Seal System: Ternary ethylene propylene rubber sealing strip
3 Customers’ stipulated brand are available.
-
Semi-exposed Framing Glass Curtain Wall
Certificate ISO9001:2000
Others:
1 Screens are available.
2 Performance parameters; Sound Insulation, Water/Wind Pressure/Air Permeation Resistance
Packing:
1. inside packing: Thick paper and polyfoam for first protection.
2. outside packing: wooden shelf for the second protection.
Our products is fully designed to international standard like AAMA,ASTM,EN,BS,AS,CANS.etc and is being tested according to Australian Standard AS4284. For more technical information about our products , please contact Shanghai Metal for further information.
Also can be as your request.
