Navigation Buoy, Marine Buoy, UHMWPE Buoy

    Navigation Buoy, Marine Buoy, UHMWPE Buoy


    Used for guide the navigation and location of the ships, mark the obstruction and warnings

Details of Navigation Buoy, Marine Buoy, UHMWPE Buoy:

The light house is a special mark to guide the navigation and location of the ships, mark the obstruction and warnings. It is made up by the pillar, platform and foundation. The platform is used to install the signal lights to provide light and signals for the ships. The pillar is used to support the platform.

The new generation of UHMWPE navigation buoy is maintenance free, collision resistant, corrosive resistant and environment friendly
The plastic navigation buoy is made by ultra high molecular weight polyethylene material with more than 2.0 million molecular weight, and it can work at the temperature ranging from -70℃ to 80℃.

Specification of Navigation Buoy, Marine Buoy, UHMWPE Buoy:

Size

Diameter
mm

Buoying Depth
m

Free Boardmm

Focal Plane Heightmm

Net
Weight
kg

Heightmm

Reserve
Buoyancy
kg

CB800

800

1.5-10

450

1580

195

2900

230

CB1200

1200

2-20

510

2040

550

3380

570

CB1500

1500

4-20

632

2524

681

4100

1012

CB1800

1800

6-30

722

3031

1686

5034

1546

CB2100

2100

8-40

800

3518

1900

5757

2450

CB2400

2400

10-50

975

4527

2973

6930

4015

CB3050

3050

15-60

1114

5164

3490

7610

7646

CB3500

3500

20-70

1240

6090

3863

8520

11380

Package of Navigation Buoy, Marine Buoy, UHMWPE Buoy:

Application of Navigation Buoy, Marine Buoy, UHMWPE Buoy:

1) Mooring

2) Lighting

3) Navigation
